Profila T 696 EB

PT696EB

Length: 7,12 m
Sleeping areas: 2

Profila T 696 EB

360° Panorama:

Please click the button below to load the content from Matterport Panorama.

With the loading of the panorama you accept the privacy policy of MatterPort
Mehr erfahren

Load content

Technical data

Basic vehicle Mercedes Benz / AL-KO
Engine models 2,0 ltr.
Engine models (optional) 2,0 ltr.
Double floor height (mm) 195
Wheelbase (mm) 4107
Tyres 225/75 R16C(235/60 R17C)
Total techn. perm. Weight when laden (kg)( 1 ) 3500 / 4500 kg
Weight in ready-to-drive state* (kg)( 2 ) 2948 (2801 - 3095)
Trailer weight* (braked) (kg) 2000 kg
Maximum dimensions for packages and optional extras( 4 ) 42,80
Total length (mm) 7124
Total width (mm) 2320
Total height (mm) 2920
Interior width (mm) 2174
Standing height (mm) 1975
Front side seating group (mm) 1150 x 1050
Bed conversion of the seating group (mm)( 3 ) (2000 x 1150)
Rear bed (mm) 1900 x 8001850 x 800
Extension to X sleeping areas 4
Permissible number of people with 3-point seatbelts total*( 3 ) 4
Wall thickness of wall (mm) 30
Wall thickness of roof (mm) 30
Wall thickness of floor (mm) 38
Fresh water tank (l)( 5 ) 140 ltr.
Waste water tank (l)( 5 ) 10 ltr.
Battery capacity (Ah) 1 x 80 Ah Gel
Water volume in drive position (l) 88 ltr.
(1)The technically permissible overall weight in a laden state refers to the overall weight defined by the manufacturer that the vehicle may not exceed when in drive mode. (2)The weight in ready-to-drive state refers to the weight of the vehicle (with standard features according to the manufacturer's specifications) with its fuel tank filled to at least 90% of capacity and includes the weight of the driver (which is calculated at a nominal value of 75 kg), the weight of the fuel and fluids, the weight of the superstructure and the driver's cab, and the weight of the towing hitch and the tyre repair kit (to the extent these are present). This represents a calculated value that is subject to legally permissible fluctuations of up to ± 5% (see additional text in brackets). Since these legally permissible fluctuations impact the vehicle's payload and therefore also the weights of the packages and special equipment that can be ordered, the occurrence of such fluctuations must be factored into the configuration process and the choice of packages and special equipment. (3)The weight of the passengers is calculated at a nominal 75 kg per seat, whereas the weight of the driver, which was already taken into account in the weight in the ready-to-drive state, must be deducted. In the case of a vehicle with four belt-restrained seats, the weight of the passengers is therefore 225 kg (3 x 75 kg). (4)The maximum weights for packages and special equipment represent a value calculated for each floor plan with which we have restricted the weights for the packages and special equipment that can be ordered from the factory. This is intended to ensure that the legally prescribed minimum payload is complied with after the vehicle is shipped from the factory. If the configuration process leads to the upper limit for this defined by the manufacturer being exceeded as a result of the choice of packages and special equipment, you can only continue with the configuration process if you de-select packages, special equipment or belt-restrained seats or choose to in-crease the vehicle's load capacity. Otherwise, you will not be able to configure or ordering the configured vehicle. Please note that the calculation of the maximum weights for packages and special equipment also takes into account the special equipment features of the selected country variation / the selected special model. The selected vehicle is currently shown in the country variation United Kingdom. Important information regarding vehicle weights can be found here (5)Please note that the capacity of the fresh water tank is significantly reduced in the drive position. If the payload of the individual vehicle is sufficient, it can be filled to its full capacity.

Equipment

Engine

serial/optional
Mercedes-Benz 170 HP motor serial
